CJF2000 linear weigher

CJF2000 linear weigher

This linear weigher is consist of 4 pairs feeding hopper, each pair consists of one fast feeding hopper and one slow feeding hopper, this design is for keeping the speed and accuracy, it is always works with bagging machine for realize functions of automatically weighing ,filling ,bag-making ,sealing ,cutting, date -printing, etc.

  • Item NO.:

    ZY202006127
  • Lead Time:

    20 working days
  • Product Origin:

    China
  • Brand:

    zengran
  • Shipping Port:

    Shanghai Port
  • Payment:

    L/C、D/A、D/P、T/T、Western Union、MoneyGram
  • Price:

    $13000/SET
  • Market Price:

    $13000
  • Price Range:

    5-10/12000$
  • Inventory:

    200
  • MOQ:

    1
Products Details

CJF2000 linear weigher



CJF2000 linear weigher


Indroduction:

Thislinear weigher is consist of 4 pairs feeding hopper, each pair consists of one fast feeding hopper and one slow feeding hopper, this design is for keeping the speed and accuracy, it is always works with bagging machine for realize functions of automatically weighing ,filling ,bag-making ,sealing ,cutting, date -printing, etc.



Technical features:

No.

Features

1

Equip with weighing control module for keeping the weighing accuracy

2

This linear weigher is consist of 4 pairs feeding hopper, each pair consists of one fast feeding hopper and one slow feeding hopper, this design is for keeping the speed and accuracy,

3

Own independent touch screen for setting technical parameters

4

works with bagging machine for realize functions of automatically weighing ,filling ,bag-making ,sealing ,cutting,date -printing, etc.

5

Parts contact with materials are made by SUS304.

6

Suitable for weighing granules, like beans, rice, seeds, detergent powder, corns,etc.


Application:

Granule: grain, granular drug, capsule, seed,fertilizer, condiments, granulated sugar, chicken essence, melon seeds, nuts etc.



Working Progress:



Manual put materials in DT2 bucket elevator →DT2 bucket elevator will feeding granules in hopper  of the CJF2000 linear weigher → Automatic weighing and filling granules in bags or bottle



Technical Form:

No.

Item

Parameter

1

Metering way

Weighing module control feeding hopper

2

Packing weight

100g~2kg

3

Packing accuracy

±0.2%

4

Packing speed

30~45bags/min(depending on actual material)

5

Voltage

220V,1P,50HZ

6

Power supplier

1.5KW

6

Weight

350kg

7

Hopper volume

200L

8

Material

Parts contact with material are made of SUS304 stainless steel



Main configuration list:

NO

Components

Brand

Origin

1

Load cell

ZEMIC

CHINA

2

Cylinder

AIRTAC

Taiwan

3

Vibrator

Xinyue

CHINA
